Sky Map


Current view of the sky over SETI Net. Click for a full size view

The blue band is the milky way. The '+' is the star location being searched. The 'O' is the antenna position.  The size of the 'O' is the beam width.  When the '+' and 'O' overlap the antenna is locked and tracking.  L4 and L5 are shown.

The Sine Wave is the minimum El of the antenna.  The spike is the mechanical stop on Azimuth.

Station Status

Google Search

This is the current operating status of the station. This is updated every minute during normal operation. Click to enter the home page.

Please note: At times the Status will show a different Station name. This happens when a new station posts its data.

Spectrum Analyzer

Click  to see a current Spectrum Analyzer snapshot.  The vertical scale is amplitude in mVolts audio.  The horizontal scale is frequency.  The curve shape is due to the non-linearity of the audio output of the receiver in use.  A peak 20% higher than the average of its 10 neighbor bins will trigger the alarm and start recording .

The upper, Red, spectrum is the maximum level tested for signals. Anything above this arbitrary level is ignored.
